Application：

Stator I.D.：30~100 mm

Stator O.D：Max. 160 mm

Stack Height：Max. 120 mm

Number Of Slots：8~36 Slots

Specifications：

Operation Method：Servo motor

Motor：3phase  3 75 kw

Dimension：1700(L)×800(W)×1700(H) mm

Weight：1300 kgs

Function：

Wedge is inserted automatically in accordance with stack height of stator, and coil can be inserted automatically with one pass in compliance with specification of winding by transfer tool. It can enhance insertion efficiency highly, and reduce the production cost.

Features：

1. High speed automatic insertion, labor saving, cost reduction and stable quality output.

2. Easy and quick to change tool according stack height of stator.

3. Change different tool to meet different kinds of stator.
